2.54mm right angle pin header connector
2.54mm right angle pin header connector is the right angle version of the board to board connector belonging to 2.54mm pin header series. This connector is best known for providing co-panel solutions with a female header in PCBs. While the single row type of this connector can be easily inserted in to the female header the double row types take a little more effort in to counts.
Features
Great many variants
A single row connector can have two to forty pins on one side or both sides. In case of dual row connectors the connector can have four to 80 pins for connecting it with the female headers.
Metal contact
The connector has metal contacts which are made of copper alloy most of the time. You can get custom made insulator with the connector.
Compatibility
The connector is compatible with the female counterpart of the connector having same specification as this type of connector.
Applications
LCD panel
The connector is used in all sorts of LCD panels in various industries and household applications. This is a great product for automotive industries and home consumables using the LCD.
Fabrication
This connector can be used in various applications involving its connection with straight, right angle and surface mount female counterparts.
General Overview:
2.54mm (.100”) inch right- angle pin header is PCB headers for board to board connectors connection.This product include: single and dual row in Right angle version, three and four row can also be made according to customer’s request. It’s breakaway pin header, can cut into any pins easily. Generally mated with receptacle or stackable header connectors (female sockets) which is vertical, right-angle or SMT (surface mount) application. Assemble at the edge of PCB board connect with female header for co-panel solution.
This types of pin headers are suitable for PCB board to board connection or for signal transmission application.
Feature:
-Contacts: 2-40 pins for single row and 4-80 pins for dual row.
-Breakaway: 1×40 pins is typical breakaway pin headers connector.
-Orientation: Right-angle through hole
-Highly customized: Insulator height profile can be design to double or more to match the current you need. Pins length can be modify according to the distance of PCB board you need.
-Materials: Metal contact material: Copper Alloy ( Brass or Phosphor Bronze)
-Insulator: PBT UL 94V-0 or custom
Here is some hot goods in Right angle version: samll pins like 2 3 4 6 8 headers.
Application
Board to board connectors or Signal application:
-Electronic device
-Home appliances
-Electrical instruments
-Automotive: Car navigation LCD panel and so on.
-Lighting industry
The above applications are typical but not limited, these products are widely use in many fields. for more information or have any advice please contact Smolex.
